KnightX 100
(4G CAT 1）
Battery Asset Tracker
Completed Certificates
KnightX 100 has completed key international certifications, including CE, FCC, RCM, Anatel, NBTC, CITC, and TDRA, confirming compliance for battery-powered asset tracking deployments in logistics monitoring, asset security, and regionally regulated projects across Latin America, the Middle East, and Asia-Pacific. These certifications support stable low-power operation, flexible deployment, and reliable asset visibility for fleet-related and logistics tracking applications.
KnightX 100 is advanced rechargeable battery powered tracker with panic button, optional temperature probe for wide ranging applications.
Features
Real time and buffer locations
Real time location updates can be as frequent as 3s. Location points can be saved in buffer if out of network coverage.
Movement alerts
Alerts for start and stop moving
Temperature probe
Optional external temperature probe
Real time and buffer locations
Real time location updates can be as frequent as 3s. Location points can be saved in buffer if out of network coverage.
Movement alerts
Alerts for start and stop moving
Temperature probe
Optional external temperature probe
No installations
It can be simply left in properties without any installation
No installations
It can be simply left in properties without any installation
WIFI positioning
GPS + WIFI +LBS positioning for different scenario
Long life battery
Rechargeable 6400 mAh / 3.7V battery
WIFI positioning
GPS + WIFI +LBS positioning for different scenario
Long life battery
Rechargeable 6400 mAh / 3.7V battery
IP67 waterproof
Not for outdoor uses
BLE 5.1
BLE for wireless sensors and accessories
IP67 waterproof
Not for outdoor uses
BLE 5.1
BLE for wireless sensors and accessories
Technical Specifications
Network/Operating Band
LTE FDD Cat 1: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/ B20/B25/B26/B28/B66
LTE TDD Cat 1: B34/B38/B39/B40/B41
GSM: 850/900/1800/1900 MHz
Battery Life
2 hours active tracking per day:
10 min reporting – 215 days
5 min reporting – 141 days
1 min reporting – 38 days
GNSS Specifications
GNSS Chipset: All-In-One GNSS Receiver
Parallel GNSS: GPS + Glonass + Beidou + Galileo +QZSS
Horizontal Position Accuracy: Autonomous: < 1.5 m CEP
TTFF @ -130 dBm with (without) EPO:
Cold start: < 15s (30s)
Warm start: < 2s (25s)
Hot start: < 2s (2s)
Interfaces
Data Transmission: USB-C
Network, GNSS, WIFI Antenna: Internal only
Indicator LED: Network, GNSS and Power
FOTA: Yes
Temperature Sensor: 1 internal, and optional external temperature probe
General Specifications
Waterproof: IP67
Dimensions: 91.8mm*43.5mm*29.2mm(”3.61 *1.71” *1.14”)
Weight: 165g(5.85oz)
Battery: Lithium-ion 6400mAh/ 3.7V
Data Communication: USB-C cable
Operating Temperature: -20℃ ~ 80℃ (-4°F ~176°F)
Air Interface Protocol
Transmit Protocol: TCP, UDP, MQTT, SMS
Data Security & Encryption Option: MD5/AES
Low Power Alarm: Sending alarm when battery is low
Certification
CE, FCC, RCM, Anatel, NBTC, CITC, TDRA
Optional Accessories
Installation Bracket
Mounting Magnet
Temperature Probe
