The Plug & Play OBDII tracker with CAN BUS reading for tracking vehicles and providing insight vehicle data such as ignition, VIN, odometer, fuel level, etc. When working with BLE sensors it can monitor the temperature, humidity, door status, etc. It’s a vehicle tracker that requires no installation and maintenance but offer powerful functions.
Features
Real time and buffer locations
Real time location updates can be as frequent as 3s. Up to 60,000 location points can be saved in buffer if out of network coverage
Plug & Play
No installation and maintenance needed
CAN BUS reading
VIN/odometer/fuel level/RPM/DTC
Driving behaviour detection
Detecting reckless driving events such as harsh acceleration, turning, braking, crash and speeding
BLE 4.0 for sensors
Compatible with TOPFLYtech’s BLE temp & humi senor TSTH1-B, temp & door sensor TSDT1-B, wireless relay TSR1-B and your own sensors
Compact size
One of the smallest OBDII trackers in the market
Disconnection alerts
Alerts for device disconnected from power
Backup battery
Backup power for sending disconnection alerts when power disconnected
Ignition on/off alerts
Alerts for engine is switched on or off
Technical Specifications
2G Quad band: 850/900/1800/1900 MHz
GNSS Chipset: All-In-One GNSS receiver
Parallel GNSS: GPS+Glonass/ GPS+Galileo/ GPS+Beidou
Receiver type: 33 tracking / 99 acquisitions- channel GNSS receiver
Sensitivity: Cold start: -148 dBm
Reacquisition: -163 dBm
Tracking: -165 dBm
Position Accuracy (CEP): Autonomous: < 2.5m
TTFF (Open Sky): Cold start: < 28s
Warm start: < 26s
EPO assist: < 13s
Hot start: < 1s
GSM/GNSS/Bluetooth Antenna:Internal only
Indicator LED:Network, Diagnostics and GNSS
Dimensions:57mm*50mm*24mm (2.24” *1.97” *0.94”)
Weight:50g (1.76oz)
Backup Battery:Li-Polymer 120 mAh/ 3.7V
Operating Voltage:7V to 32V DC
Operating Temperature:-30℃ ~ +80℃ (-22°F ~ 176°F)
Storage Temperature:-40℃ ~ +85℃ (-40°F ~ 185°F)
