T-sense
BLE 5.1 Temperature & Door Sensor
It collects the temperature of the environment and transmits the data via BLE to trackers or BLE hub, then transmitted to server finally. It is designed for the demands of the environmental monitoring industry to resolve losses caused by unexpected and unfriendly temperature changes.
Features
BLE 5.1
It can be used for data broadcasting and wireless configuration
High accuracy
Accuracy of ± 0.2 ℃ for temp
Frequent data broadcasting
Broadcasting data every 10s by default (configurable)
BLE 5.1
It can be used for data broadcasting and wireless configuration
High accuracy
Accuracy of ± 0.2 ℃ for temp
Frequent data broadcasting
Door status
Real time monitoring for door status
Door status
Real time monitoring for door status
Wide transmission range
Operating distance up to 400m (open field)
Wide range of operating temperature
Operating between -30℃ ~ +80℃ (-22°F ~ 176°F)
Wide transmission range
Operating distance up to 400m (open field)
Wide range of operating temperature
Operating between -30℃ ~ +80℃ (-22°F ~ 176°F)
Historical data storage
Can store up to 15,000 temperature and humidity data in sensors to be extracted by phone
FOTA
Firmware upgrade Over-the-Air
Historical data storage
Can store up to 15,000 temperature and humidity data in sensors to be extracted by phone
FOTA
Firmware upgrade Over-the-Air
Technical Specifications
Waterproof: IP67
Dimensions: 59.9mm * 40.0mm * 14.6mm (2.36 “* 1.57″ * 0.57”)
Weight: 23g (0.81oz, battery included)
Battery: Non-replaceable CR2477 battery (1000mAh)
Operating temperature: -30℃ ~ +80℃ (-22°F ~ 176°F)
Temperature accuracy (0-60 ℃) ： ± 0.2 ℃ (Typical long-term drift <0.02 ° C / year)
Open field transmission range (BLE 5.1): Up to 200m (656 fts) @ 4 dBm (default). Up to 400m (1312 fts) @ 8 dBm
TFT Eddystone: Yes
Eddystone UID: Yes
Beacon: Yes
Others: Door sensor (default off)
TFT Eddystone (default)
1100 days @ interval: 5s & TX= 4 dBm (default) & temperature = 25ºC & Temperature on (default) & Accelerometer on (default off) & Magnetometer on (default off)
1600 days @ interval: 10s & TX= 4 dBm (default) & temperature = 25ºC & Temperature on (default off) & Accelerometer on (default off) & Magnetometer on (default off)
980 days @ interval: 5s & TX= 8 dBm & temperature = 25ºC & Temperature on (default) & Accelerometer on (default off) & Magnetometer on (default off)
1400 days @ interval: 10s & TX= 8 dBm & temperature = 25ºC & Temperature on (default) & Accelerometer on (default off) & Magnetometer on (default off)
Beacon or Eddystone UID
2200 days @ interval: 5s & TX= 4 dBm
1900 days @ interval: 5s & TX= 8 dBm
2700 days @ interval: 10s & TX= 4 dBm
2500 days @ interval: 10s & TX= 8 dBm
